23 Inches Rack mount  Monitor :
Part # LCDR8U23-02


    SiriusView 8U Rack Mount  23"  Widescreen  LCD Monitor Panel for  24" wide  Rack
Optional Lexan Shield

Made in U.S.A.  TAA Compliant

                                                                     * Click on image for  enlarged view
        Free Ground Shipping *Click for details



Features :
- Mounts in 8U vertical rack space in a 24" wide rack. TAA Compliant
- 23" Wide fromat TFT LCD display with 1680 x 1050 resolution.
- Fast video response time provides shap text and crisp motion.
- 16:10 aspect ration features a widescreen viewing area.
- Stell front panel construction with a durable paint finish.
- Optional Lexan Screen protection available.
- Color : Black

The LCDR8U23-02 rack mountable 23"  TFT monitor provides a high contrast, wide viewing angle display in a minimal rack depth. This TFT display connects directly to a standard video output via a 15-pin VGA connector and does not require any additional drivers or proprietary interface adapters. Also featured is a connection to DVI-D digital video devices. Offered in black with optional display surface Lexan Shield protection.

Click on the following photos for enlarged view :


Display Type 23 " TFT active matrix with IPS LCD
Resolution Full HD Native Resolution : 1920 x 1080 maximum, 16.7M colors.
Compatibility PC/Windows, Macintosh
Frequency Horizontal: 30-81 KHz.
Vertical: 56-75 Hz.
Pixel Pitch .282 mm
Response Time 14 ms Typ
Brightness 250 nits typical
Contrast Ratio 1000:1 typical
Syn Type Separate H/V, Composite H/V, SOG.
Temperature: Operating: 10°C to 40°C
Storage: -20°C to 45°C
Viewing Angle Horizontal: 178 degrees
Vertical: 178 degrees
Input Signal (VGA) R.G.B. analog
(Digital) DVI-D (with HDCP).
Video Connector Analog: 15 pin D-sub.
Digital: 24 pin DVI-D.
On-Screen Controls Brightness, Contrast, Position (Vert. & Horiz.), OSD H & V position, Input Select, Color Temp., Reset. Auto Adjust
Plug & Play DDC2B
Power AC Input 100-240VAC
Frequency 50/60 Hz
Power Consumption 55 Watts Max
Environment
Humidity Operating: 10% to 80% RH (max)

Ordering  information
Part Number  Description
LCDR8U23-02-b  8U Rack Mount  23" WideScreen LCD Monitor for 24" wide Rack , Black
LCDR8U23-02-b-lex  8U Rack Mount 23" WideScreen LCD Monitor for 24" wide Rack, with Lexan Shield protection at display ,
 Black
