       SUNLIGHT READABLE DISPLAY
 -  LCD PANEL SIZE :    17" ~ 42"
 -  STYLE : Panel Mount Sunlight LCD /  Open Frame  Sunlight LCD
 /
  Chassis Display Sunlight LCD

   FREE GROUND SHIPPING  *** Click for details

Panel Mount Style Sunlight Readable LCD
Part # / Photo / Price/ Buy Online LCD Size Resolution Contrast Ratio
 /  Brightness
Viewing Angle Dimension Features & Options
 ID-H42Aw-LED
Buy Online>>
Wide 42"
(16:9)
 1920 x 1080  3000:1 / 1500 cd/m2 178° x 178°
1051 x 105.8 x 644 mm (WxDxH)
*High brightness LCD w/ LED-backlit
*Full HD LCD display
*PIP & Picture by Picture viewing efficiency

   0PTIONS :
  • MIL-type or lockable connector
  • Auto / switch dimming
  • 48V or 24VDC power
  • TV - Analog
  • MC: Multi-Display Controller
  • 3G / HD / SD-SDI input
  •  ID-H22Aw-LED
    Wide 22"
    (16:10)
     1680 x 1050

     1000:1 / 1000 nits

    160° x 160° 574 x 64 x 380 mm (WxDxH) *Sunlight LCD with LED Backlight Panel
    - Options : - MC Multi-display control
    - MIL-type or lockable connector
    - TV - PAL or NTSC
    - 3G / HD / SD-SDI Broadcast-grade input
    - HDMI, DVI-D, S-Video + BNC & Audio
    - 22" Touchscreen
     ID-H22Aw
    22"W
    (16:10)
    1680 x 1050 900:1 / 600 nits 170 /160 degree 574 x 62 x 380 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI, S-Video & Composite Video
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-HE21Aw
    Buy Online>>
    Wide 21"
    (16:10)
     1920 x 1080  5000:1 / 1000 cd/m2 178° x 178° 577.8 x 59.1 x 369.3 mm (WxDxH) *Sunlight High Resolution LCD Panel
       0PTIONS :
  • 21" Touchscreen
  • MIL-type or lockable connector
  • TV - Analog
  • MC: Multi-Display Controller
  • 3G / HD / SD-SDI
        Broadcast-grade input
  • S-Video + ( BNC ) or Audio input
  • 48V, 24V or 12VDC power
  • Auto / switch dimming
  •  ID-H19Aw-LED
    Wide 19"
    (16:10)
     1440 x 900  1000:1 / 1000 cd/m2 160° x 160° 509 x 66 x 338 mm (WxDxH) *High Resolution LCD Panel
    - Options : - TV - PAL or NTSC
    - touch screen
    - MC Multi-screen control via serial solution
    - 3G / HD / SD-SDI Broadcast-grade input
    - MIL-type or lockable connector
    - 48V or 24VDC Power
    - HDMI, DVI-D, S-Video + BNC & Audio
     ID-H19Aw
    19"W
    (16:10)
    1440 x 900 900:1 / 800 nits 160 /160 degree 508 x 63.6 x 338.1 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI, S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-H19A-LED
    Buy Online>>
    19"  1280 x 1024  1000:1 / 1000 cd/m2 160° x 160° 477 x 64 x 384 mm (WxDxH) *High Resolution LCD Panel
    - Options: - TV - PAL or NTSC
    - touch screen
    - MC Multi-screen control via serial solution
    - 3G / HD / SD-SDI Broadcast-grade input
    - MIL-type or lockable connector
    - 48V or 24VDC Power
    - HDMI, DVI-D, S-Video + BNC & Audio
     ID-H19A
    19" 1280 x 1024 800:1 / 800 nits 160 /160 degree 476.5 x 61.6 x 384.1 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI, S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-H17A-LED
    Buy Online>>
    17"  1280 x 1024

     1000:1 / 1000 nits

    170° x 160° 439 x 64.2 x 356.6 mm (WxDxH) *Sunlight LCD with LED Backlight Panel
    -Options
  • MC Multi-display control solution
  • 17" Touchscreen : Capacitive, Resistive
  • S-Video + ( BNC ) or Audio input
  • HDMI or DVI-D
  • MIL-type or lockable connector
  • 48V or 24VDC Power
  • Quad display for CCTV
  • Auto / switch dimming
  • TV - Analog
  •  ID-H17A
    17" 1280 x 1024 800:1 /800 nits 170 /160 degree 439 x 62.2 x 356.6 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI, S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-H12A
    12.1" 800 x600 800:1 /800 nits 160 /110 degree 339.7 x 66.2 x 256 mm (WxDxH) *LG Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-H10A
    10.4" 800 x600 800:1 /1000 nits 140 /120 degree 284.7 x 60.8 x 222 mm (WxDxH) *Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-H08A
    8.4" 800 x600 800:1 /820 nits 130 /110 degree 264.7 x 60.8 x 192 mm (WxDxH) * Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-H06A
    6.5" 640 x480 500:1 /1000 nits 120 /95 degree 254.7 x 65.8 x 182 mm (WxDxH) * Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
    Open Frame Style  Sunlight Readable LCD                                                 Back to top >>
     ID-H42Pw-LED
    Buy Online>>
    Wide 42"
    (16:9)
     1920 x 1080  3000:1 / 1500 cd/m2 178° x 178°
    1048 x 99.8 x 640 mm (WxDxH)
    *Sunlight Readable LCD w/ LED-backlit
    *Full HD LCD display
    *PIP & Picture by Picture viewing efficiency

       0PTIONS :
  • MIL-type or lockable connector
  • Auto / switch dimming
  • 48V or 24VDC power
  • TV - PAL or NTSC
  • MC: Multi-Display Controller
  • 3G / HD / SD-SDI input
  •  ID-11-H24Pw

    Wide 24"

     1920 x 1080  5000:1 / 1000 Nits (cd/m2) (V/H) - 89°/89° 654 x 93 x 348 mm (WxDxH) *High Bright Sunlight Readable LCD
    •Optical Bonding
    •High-Luminance Solid-State LED-enhanced Backlighting
    •Optical Stack Enhancement
    •RoHS Compliant

       0PTIONS :
  • Optional Touch Screen
  • NEMA 4 Protection
  • Optional inputs
  • Impact Resistant Protective Windows
  •  ID-H22Pw-LED
    Wide 22"
    (16:10)
     1680 x 1050  1000:1 / 1000 nits 160 /160 degree
    571 x 58 x 377 mm (WxDxH)
    *Sunlight LCD w/ LED-backlit
       0PTIONS :
  • HDMI, DVI-D, S-Video + BNC & Audio
  • HW22" Touchscreen
  • 48V or 24VDC power
  • TV - PAL or NTSC
  • MC: Multi-Display Controller
  • 3G / HD / SD-SDI
        Broadcast-grade input
  • ID-H22Pw
    22"W
    (16:10)
     1680 x 1050 900:1 / 600 nits 170 /160 degree 571 x 55 x 377 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI
    -Optional S-Video & Composite Video (RCA/BNC)
    -Anti-Reflective flim, TV turner, Remote controller
    -Optional Quad display, Audio, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V DC-to-DC power input
     ID-HE21Pw
    Buy Online>>
    Wide 21.5"
    (16:10)
     1920 x 1080  5000:1 / 1000 nits 178° x 178°

    574.8 x 52.6 x 366.3 mm (WxDxH)

    *High Resolution & Sunlight LCD Panel

       0PTIONS :
  • 3G / HD / SD-SDI Broadcast-grade input
  • MC Multi-display control solution
  • 21" Touchscreen : Capacitive, Resistive
  • S-Video + ( BNC ) or Audio input
  • MIL-type or lockable connector
  • 48V, 24V or 12VDC power
  • Auto / switch dimming
  • TV - Analog
  •  ID-H19Pw-LED
    Buy Online>>
    Wide 19"
    (16:10)
     1440 x 900  1000:1 / 1000 nits 160° x 160°

    506 x 60 x 335 mm (WxDxH)

    *Sunlight LCD w/ LED-backlit

       0PTIONS :
  • HDMI, DVI-D, S-Video + BNC & Audio
  • 19" Touchscreen
  • 48V, 24V or 12VDC power
  • TV - PAL or NTSC
  • MC: Multi-Display Controller
  •  ID-H19Pw
    19"W
    (16:10)
     1440 x 900 900:1 / 800 nits 160 /160 degree 505.5 x 57.1 x 335.1 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI, S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V power input
     ID-11-H19P

    19"

     1280 x 1024  1000:1 / 1000 Nits (cd/m2) Up/Dwn/L/R: 85°/85°/ 85°/85° 479 x 91 x 353 mm (WxDxH) *High Bright Sunlight Readable LCD
    •Optical Bonding
    •High-Luminance Solid-State LED-enhanced Backlighting
    •light management films
    •RoHS Compliant

       0PTIONS :
  • Optional Touch Screen
  • NEMA 4 Protection
  • Optional inputs
  • Impact Resistant Protective Windows
  •  ID-H19P-LED
    Buy Online>>
    19"  1280x 1024  1000:1 / 1000 nits 160° x 160°

    474 x 58 x 381 mm (WxDxH)

    *Sunlight LCD w/ LED-backlit

       0PTIONS :
  • HDMI, DVI-D, S-Video + BNC
       & Audio
  • 19" Touchscreen
  • 48V or 24VDC power
  • TV - PAL or NTSC
  • MC: Multi-Display Controller
  •  ID-H19P
    19"  1280 x 1024 700:1 / 800 nits 150 /135 degree 473.5 x 55.1 x 381.1 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI
    -Optional S-Video &
     Composite Video
    -Optional BNC
    -Optional Touch Screen
    -Optional 12V/24V/48V DC
      Input adapter
     ID-11-H17P

    17"

     1280 x 1024  1000:1 / 1000 Nits (cd/m2) Up/Dwn/L/R: 85°/85°/ 85°/85° 403 x 78 x 297 mm (WxDxH) *High Bright Sunlight Readable LCD
    •Optical Bonding
    •High-Luminance Solid-State LED-enhanced Backlighting
    •light management films
    •RoHS Compliant

       0PTIONS :
  • Optional Touch Screen
  • NEMA 4 Protection
  • Optional inputs
  • Impact Resistant Protective Windows
  •  ID-H17P-LED
    Buy Online>>
    17"  1280x 1024  1000:1 / 1000 nits 170° x 160°

    436 x 58.2 x 354 mm (WxDxH)

    *Sunlight Readable LCD w/ LED-backlit

       0PTIONS :
  • MC Multi-display control solution
  • 17" Touchscreen : Capacitive, Resistive
  • S-Video + ( BNC ) or Audio input
  • HDMI or DVI-D ( either one )
  • MIL-type or lockable connector
  • 48V or 24VDC power
  • Quad display for CCTV
  • Auto / switch dimming
  • TV - Analog
  •  ID-H17P
    17"  1280 x 1024 500:1 / 800 nits 140 /110 degree 436 x 55.7 x 353.6 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional DVI
    -Optional S-Video &
     Composite Video
    -Optional BNC
    -Optional Touch Screen
    -Optional 12V/24V/48V DC
      Input adapter
     ID-11-H15P

    15"

     1024 x 768  600:1 / 1500 Nits (cd/m2) Up/Dwn/L/R: 80°/60°/ 80°/80° 381 x 63 x 285 mm (WxDxH) *High Bright Sunlight Readable LCD
    •Optical Bonding
    •High-Luminance Solid-State LED-enhanced Backlighting
    •light management films
    •RoHS Compliant

       0PTIONS :
  • Optional Touch Screen
  • NEMA 4 Protection
  • Optional inputs
  • Impact Resistant Protective Windows
  •  ID-11-H12P

    12.1"

     1024 x 768  600:1 / 1000 Nits (cd/m2) Up/Dwn/L/R: 80°/60°/ 80°/80° 305 x 64 x 226 mm (WxDxH) *High Bright Sunlight Readable LCD
    •Optical Bonding
    •High-Luminance Solid-State LED-enhanced Backlighting
    •light management films
    •RoHS Compliant

       0PTIONS :
  • Optional Touch Screen
  • NEMA 4 Protection
  • Optional inputs
  • Impact Resistant Protective Windows
  •  ID-H12P
    12.1" 800 x600 800:1 /800 nits 160 /110 degree 341.7 x 59.7 x 253 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V DC-to-DC power input
     ID-11-H10P

    10.4"

     800 x 600  900:1 / 1200 Nits (cd/m2) Up/Dwn/L/R: 80°/60°/ 80°/80° 284 x 54 x 216 mm (WxDxH) *High Bright Sunlight Readable LCD
    •Optical Bonding
    •High-Luminance Solid-State LED-enhanced Backlighting
    •light management films
    •RoHS Compliant

       0PTIONS :
  • Optional Touch Screen
  • NEMA 4 Protection
  • Optional inputs
  • Impact Resistant Protective Windows
  •  ID-H10P
    10.4" 800 x600 800:1 /1000 nits 140 /120 degree 281.7 x 54.3 x 219 mm (WxDxH) *Samsung Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V DC-to-DC power input
     ID-11-H08P

    8.4"

     800 x 600  600:1 / 1200 Nits (cd/m2) Up/Dwn/L/R: 80°/60°/ 80°/80° 241 x 69 x 202 mm (WxDxH) *High Bright Sunlight Readable LCD
    •Optical Bonding
    •High-Luminance Solid-State LED-enhanced Backlighting
    •light management films
    •RoHS Compliant

       0PTIONS :
  • Optional Touch Screen
  • NEMA 4 Protection
  • Optional inputs
  • Impact Resistant Protective Windows
  •  ID-H08P
    8.4" 800 x600 800:1 /8200 nits 140 /110 degree 261.7 x 54.3 x 189 mm (WxDxH) * Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V DC-to-DC power input
     ID-H06P
    6.5" 640 x480 500:1 /1000 nits 120 /95 degree 251.7 x 59.3 x 179 mm (WxDxH) * Grade A LCD Panel
    -Optional S-Video & Composite Video (RCA/BNC)
    -Optional Audio, TV turner, Remote controller
    -Optional Anti-Reflective flim, Optical bonding
    -Optional Touch Screen
    -Optional 12V/24V/48V DC-to-DC power input




    Toll Free : 1-888-865-6888    Fax : 510-226-8968    Email : sales@RackmountMart.com






    Home    |   Buy Online    About Us  |    Contact Us    |    Site Map

    Product images may be generic and may not reflect actual item purchased. Synergy Global Technology Inc is not responsible for any typo graphical errors. Specifications & prices subject to change without notice.  Legal.
