                            CHASSIS DISPLAY
                            -  LCD PANEL SIZE :    Ratio 4: 3  -   6.4" ~ 20"      Ratio  16: 9 -  17" ~ 40"


                              FREE GROUND SHIPPING  *** Click for details

Ratio    4 : 3
Part # / Photo / Price / Buy Online LCD Size Resolution Contrast Ratio / Brightness Viewing Angle Dimension Features & Options
 ID-06D




    6.4"

 640 x 480  400:1 / 400 nits 120 /95 degree

213 x 46 x 150 mm (WxDxH)

* Grade A LCD Panel
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
  Input adapter
 ID-2-08DN

Price: $480  Buy Online>>
    8.4"  800 x600 600:1 / 450 nits 160x140 254 x 190 x 42 mm (WxHxD) * Grade A LCD w/ LED-backlit Panel
* with Resistive Touch Screen
* with IP65 / NEMA4 on screen
 ID-08D




    8.4"

 800 x600  350:1 / 220 nits 120 /100 degree
234 x 38 x 167 mm (WxDxH)
* Grade A LCD Panel
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
 Input adapter
 ID-2-10DN

Price: $512  Buy Online>>
    10.4"  800 x600 700:1 / 400 nits 160x140 287.6 x 245 x 43.9 mm (WxHxD) * Grade A LCD w/ LED-backlit Panel
* with Resistive Touch Screen
* with IP65 / NEMA4 on screen
 ID-10D




    10.4"

 800 x600  500:1 / 230 nits 120 /100 degree
259 x 43 x 199 mm (WxDxH)
* Grade A LCD Panel
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
  Input adapter
 ID-2-12DN

Price: $560  Buy Online>>
    12.1"  1024 x 768 700:1 / 500 nits 160x140 320.3 x 275 x 43.4 mm (WxHxD) * Grade A LCD w/ LED-backlit Panel
* with Resistive Touch Screen
* with IP65 / NEMA4 on screen
 ID-12D




    12.1"

 800 x600  200:1 / 300 nits 120 /95 degree 289 x 54 x 231 mm (WxDxH) * Grade A LCD Panel
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
  Input adapter
 ID-2-15DN

Price: $592  Buy Online>>
    15"  1024 x 768 700:1 / 350 nits 160x140 384 x 312 x 44.5 mm (WxHxD) * Grade A LCD w/ LED-backlit Panel
* with Resistive Touch Screen
* with IP65 / NEMA4 on screen
 ID-15D




    15"

 1024 x 768  400:1 / 250 nits 130 /110 degree
372 x 52 x 283 mm (WxDxH)
*Grade A LCD Panel
-Optional DVI
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
  Input adapter
 ID-17D




    17"

 1280 x 1024  700:1 / 300 nits 150 /135 degree
393 x 52 x 311 mm (WxDxH)
*Samsung Grade A LCD Panel
-Optional DVI
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
  Input adapter
 ID-19D




    19"

 1280 x 1024  700:1 / 300 nits 150 /135 degree
440 x 59 x 363 mm (WxDxH)
*Samsung Grade A LCD Panel
-Optional DVI
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
  Input adapter

 ID-20D




    20"

 1600 x 1200  800:1 / 300 nits 160 /160 degree
446 x 67 x 342 mm (WxDxH)
*Samsung Grade A LCD Panel
-Optional DVI
-Optional S-Video &
 Composite Video
-Optional BNC
-Optional Touch Screen
-Optional 12V/24V/48V DC
  Input adapter


Ratio  -  16: 9                                                                          Back to top >>
 ID-17Dw




Wide 17" (16:9)

 1280 x 768  450:1 / 400 nits 140 /110 degree 421 x 54 x 271 mm (WxDxH) *Samsung Grade A LCD Panel
-Optional TV Tuner

 ID-19Dw




Wide 19" (16:9)

 1440 x 900  700:1 / 300 nits 150 /135 degree
445 x 56 x 291 mm (WxDxH)
*Samsung Grade A LCD Panel
-Optional DVI
-Optional TV Tuner
 ID-26Dw




Wide 26" (16:9)

 1280 x 768  500:1 / 450 nits 170 /170 degree
691 x 115 x 411 mm (WxDxH)
*Samsung Grade A LCD Panel
-Optional DVI
-Optional TV Tuner
 ID-32Dw




Wide 32" (16:9)

 1366 x 768  1000:1 / 450 nits 170 /170 degree  814 x 119 x 488 mm (WxDxH) *Samsung Grade A LCD Panel
-Optional DVI
-Optional TV Tuner
 ID-40Dw




Wide 40" (16:9)

 1920 x 1080
1080P HDMI
 1200:1 / 500 nits 178 /178 degree 1006 x 115 x 589 mm (WxDxH) *Samsung Grade A LCD Panel
-Optional DVI
-Optional TV Tuner
