RoHS Compliant

Rack Enclosure are available in 4 widths : 19" Rack ( EIA Compliant) , 23" Rack ( Telco Rack / Telecom Rack ), 24" Rack (Communications Rack ) & 28" Rack ( Extra Wide for Cabling & AirFlow. ) Server Rack sizes Usable Width : 19” ( EIA Compliant ), 23”, 24” or 28” Usable Height : 14u, 20u, 24u, 30u, 35u, 40u, 42u, 44u, 48u Usable Depth : 24”, 30”, 36” or 42” PACKAGE CONTENTS 1. Frame : Patented Heavy duty Aluminum extruded welded frame rated to 2,000 lbs with casters and 2,500 lbs without casters 2. Doors : Standard – Package X : Aluminum Frame Smoked Lexan front door & Vented Steel rear door Standard – Package P : Steel Perforated front door & Steel Perforated rear door Standard – Package V : Vented smoked Lexan front door & Steel Perforated rear door                                 ( Maximum front to rear cooling ) Optional - Aluminum perforated , Solid Steel , Vented Lexan, Steel Perforated , Vented Steel or Aluminum Frame Smoked Lexan Doors for Front or/and Rear Doors. Aluminum Extruded Frame Door with 63% Perforated Open Area Standard Aluminum Frame Perforated Door Aluminum Extruded Door Frame with Perforated Insert (63% open) and lockable swing handle door Steel Perforated Door with 63% Open Area Steel frame with a 63% open insert to allow for premium ventilation, lockable swing handle, lift off hinges Option - 78% Open Perforated Solid Steel Door   The most cost effective way to secure an enclosure when front and rear ventilation is not required Lockable swing handle, lift off hinges Vented Steel Door Vent patterns at the top and bottom of the door Removable panels for air flow control Lockable swing door handle, lift off hinges Lexan® Door With aluminum extruded frame radius to match enclosure Smoked polycarbonate resin thermoplastic panel that does not break Lockable swing door handle, lift off hinges Vented Lexan® Door Aluminum extruded door frame, with steel vented panel all around smoke gray lexan, lockable swing handle, lift off hinges Smoked polycarbonate resin thermoplastic panel does not break 3. Vertical Mounting Rails : 3 sets of "L" shaped infinitely adjustable square hole vertical mounting rails ( Universal mounting ). Not limited to 1” slots Optional - 10-32 Tapped Rails - 12-24 Tapped Rails 4. Side Panels : Externally Removable Side Panels Optional - Externally Removable SPLIT Side panels - Internally Removable Side panels ( for extra security & PCI compliance ) - Quick Release Sides Panels with southco latches at top and bottom support brackets - Quick Release Sides Panels with with EMKA 1091-U143 latches (2 per panel) with catch    plates at top and welded support brackets at bottom. Externally removable, Keyed #333. Externally Removable Side Panels Externally removable Externally Removable Side Panels Externally removable side panels, (4) Piece Set (2) on left, (2) on the right Quick Release Side Panels Quick release side panels with southco latches at top and bottom support brackets (set of 2) Internally Removable Side Panels Internally removable side panels for extra security 5. Top Panel : Fan top with 1 x 120V, 535 CFM fan and 2 x 4-1/2" cable access holes with cover plates and grommets Optional Top Panel - - Perforated top panel with or without 2 x cable access holes and cover plates - Solid Top Panel with or without 2 x cable access holes and cover plates - Fan top with 1 x 120V, 535 CFM fan with or without cable access holes /fan pattern - Fan top with 2 x 120V 105 CFM or 535 CFM fans & 2 x cable access holes with cover - Vented top with 2 x cable access holes, grommets and cover plates , NO FAN - Vented fan top with Fan & punched/perforated fan pattern and 2 x cable access    holes, cover plates and grommets - Top panel with brushed cable entry Perforated Top Panel Perforate top panel Solid Top Panel Solid top panel Solid Top Panel Solid top panel with (2) cable access holes & cover plates Perforated Top w/ Cable Access Holes Perforated top w/ cable access holes Fan Top   With 10" , 120 V, 535 CFM fan Fan Top With Cable Access Holes   Fan top with 120V, 535 CFM fan (2) 4-1/2" holes with cover plates and grommets Fan Top With 105 Fans & Cable Access Holes Fan top w/ (2) 120V - 105 CFM fans w/ finger guards & cord w/ plug, & (2) 4 1/2" cable access holes w/cover w/ cover plates & grommets Fan Top With (2) 535 CFM Fans & Cable Access Holes Fan top with (2) 120V - 535 CFM fans with finger guards & cord with plug, & (2) 4 1/2" cable access holes w/cover plates & grommets Vented Top Panel     10" fan - NO FAN Vented top with (2) 4 1/2" cable access holes, with grommets and cover plates - vent pattern Vented Fan Top With Fan   Fan top (With Fan) has punched/perforated fan pattern and (2) 4 1/2" cable access holes with grommets and cover plates     6. Base : Low-Profile Casters Aase with Leveling Feet Optional - Bolt Down Base, Flush Bolt Down Base, Internal Bolt Down Base, Floor Style Base, Wireway Base. Click for details. Floor Style Base Internal Bolt Down Base Caster Base Bolt Down Base Wireway Base Flush Style Base   Low Profile Base       Optional - Solid bottom Panel with or without cable access, Perforated bottom panel with or without cable access. Click for details. Bottom Panels Perforated bottom panels Solid bottom panels Perforated bottom panel with cable access Solid bottom panels with cable access 7. Mounting Hardware Pack: - 40 sets of M6 cage nuts and screws 8. Color : Black Optional - Pearl White, Granite, Platinum, White, Dark Gray, Blue or Customized color 9. Others : - Assembled - RoHS Compliant - One year warranty - The premium rack enclsoure is Made to Order. Non-Returnable Item. - Made in USA

30” deep ( Usable )						Back to Top
Height	Inside Dims	Outside Dims	Package X Aluminum frame smoked Lexan front door & Vented Steel rear door	Package P Steel Perforated front door & Steel Perforated rear door	Package V Vented smoked Lexan front door & Steel Perforated rear door
14U	24.5"H 19"W 30"D	32"H 24"W 34.67"D	SY242030X	SY242030P	SY242030V
24U	42"H 19"W 30"D	49.5"H 24"W 34.67"D	SY422030X	SY422030P	SY422030V
35U	61"H 19"W 30"D	68.8"H 24"W 34.67"D	SY612030X	SY612030P	SY612030V
40U	70"H 19"W 30"D	77.58"H 24" W 34.67"D	SY702030X	SY702030P	SY702030V
42U	73.5"H 19"W 30"D	80"H 24"W 34.67"D	SY732030X	SY732030P	SY732030V
44U	77"H 19"W 30"D	84.58"H 24"W 34.67"D	SY772030X	SY772030P	SY772030V
36” deep ( Usable )						Back to Top
Height	Inside Dims	Outside Dims	Package X Aluminum frame smoked Lexan front door & Vented Steel rear door	Package P Steel Perforated front door & Steel Perforated rear door	Package V Vented smoked Lexan front door & Steel Perforated rear door
14U	24.5"H 19"W 36"D	32"H 24"W 40.67"D	SY242036X	SY242036P	SY242036V
24U	42"H 19"W 36"D	49.5"H 24"W 40.67"D	SY422036X	SY422036P	SY422036V
35U	61"H 19"W 36"D	68.8"H 24"W 40.67"D	SY612036X	SY612036P	SY612036V
40U	70"H 19"W 36"D	77.58"H 24" W 40.67"D	SY702036X	SY702036P	SY702036V
42U	73.5"H 19"W 36"D	80"H 24"W 40.67"D	SY732036X	SY732036P	SY732036V
44U	77"H 19"W 36"D	84.58"H 24"W 40.67"D	SY772036X	SY772036P	SY772036V
42” deep ( Usable )						Back to Top
Height	Inside Dims	Outside Dims	Package X Aluminum frame smoked Lexan front door & Vented Steel rear door	Package P Steel Perforated front door & Steel Perforated rear door	Package V Vented smoked Lexan front door & Steel Perforated rear door
35U	61"H 19"W 42"D	68.8"H 24"W 46.7"D	SY612042X	SY612042P	SY612042V
40U	70"H 19"W 42 "D	77.58"H 24" W 46.7"D	SY702042X	SY702042P	SY702042V
42U	73.5"H 19"W 42"D	80"H 24"W 46.7"D	SY732042X	SY732042P	SY732042V
44U	77"H 19"W 42"D	84.58"H 24"W 46.7"D	SY772042X	SY772042P	SY772042V

Back to Top
