7U Rackmount 18.4" 4K Display
Model LCDR7U19-11

SiriusView Industrial Grade 7U Rack Mount 18.4" 4K Monitor
TAA Compliant

LCD with LED backlight Panel
Display type	Industrial Grade 4K Display
Max Resolutions	3840 x 2160
Contrast ratio	1000 : 1
Brightness	300 cd/ m2
Size (diagonal)	18.4"
Panel color	1.07B
Viewing angle	85/85/85/85 ( L/R/U/D )
MTBF (hrs)	30,000
Video input	Display port 1.2 + HDMI 1.4 + HDMI 2.0
Active area (mm)	408.98H x 230.04V
Speaker	Built-in Dual Stereo Speakers
Power	Auto-sensing 100 to 240VAC, 50 / 60Hz
Mechanical
Product Dimension	18.9W x 2.3Dx 12.2H inch/ 480W x 58D x 310H mm
Net Weight	12.8 lbs
Environmental
Temperature	0 to 55 Degree Celsius (Operation) -20 to 60 Degree Celsius (Storage)
Relative Humidity	10~90%, non condensing (Operation) 5~90%, non condensing (Storage)
Shock	10G peak acceleration ( 11ms duration )
Vibration	10~300Hz, 0.5G random vibration
Compliance	FCC, CE CE / LVD & UKCA REACH RoHS3 / WEEE TAA Compliant

User Manual

Data Sheet

Free Ground Shipping. Learn More.

DISPLAY BENEFITS :

7U rackmount 18.4" widescreen LCD

3840 x 2160 native resolution /
Support 1920 x 1080 & 1920 x 1200

PIP Sub-screen & PBP Dual-screen viewing efficiency

TAA Compliant

0PTIONS :

12G / 4K60 / SD-SDI Broadcast-grade input
3G / HD / SD-SDI Broadcast-grade input
Multi display OSD controller via serial
IP65 front protection
21" Touchscreen : Capacitive, Resistive
250V , 125V , 110V , 48V, 24V or 12V DC power
MIL-type or lockable connector

Ordering Information

Part Number Description

LCDR7U19-11
7U Rackmount 18.4" 4K Display with DP-1.2 + HDMI-2.0 + HDMI-1.4 + Speaker

Optional NEMA4 / IP65

-IP65
NEMA4 / IP65 Protective Glass

Optional Video/Audio inputs

-12G-SDI 12G-SDI + DP-1.2 + HDMI-1.4 + Speaker

-3G-SDI
3G-SDI + DP-1.2 + HDMI-2.0 + HDMI-1.4 + Speaker

-MC
MC + DP-1.2 + HDMI-2.0 + HDMI-1.4 + Speaker

Optional Touch screen

-TRB
Resistive 1-Point Touch Screen with USB Controller

-TPC Projected Capacitive 10-Point Touch Screen with USB Controller

Optional DC Input Power

-DC12 Change to 12V DC power supply

-DC24 Change to 24V DC power supply

-DC48 Change to 48V DC power supply

-DC110
Change to 110V DC power supply

-DC125
Change to 125V DC power supply

-DC250
Change to 250V DC power supply

Optional Lockable Jack

-MD MIL-type Lockable DC Power jack, Male

-MA MIL-type Lockable VGA jack, Male

-LD Lockable DC Power jack, Male

-LS Lockable USB jack for touch screen
