4U Rackmount Chassis w/ LCD Monitor & Touchscreen
Model RM4018


 Front View


***Click on above photo for enlarged view

 Dimension Drawing :


***Click on above photo for enlarged view

Features :
  • 0.05" SECC heavy-duty steel electroplate for chassis
  • Designed by the lockable door of front panel for protecting the system secutiry
  • Designed the anti-vibration card clamp to keep the system stable and safety
  • Aluminum handles
  • Support AT/ATX form motherboard or 14-slot backplane
LCD Screen Specification
LCD Type TFT LCD 6.4 inch
Resolution 640 x 480
Brightness 300 nit
Color 262,144
Input Signal Analog VGA
Touchscreen Yes, Touch screen included
Rackmount Chassis Specification
Construction 0.05" SECC heavy-duty steel electroplate for chassis
Drive Bay 2 x 5.25" CD-ROM, 1 x 3.5" FDD, 3 x  3.5" HDD
Cooling Fan Built-in two 8cm cooling fans
Power supply fan
Switch Power ON/OFF x 1, system reset x 1
Front connector One keyboard connector in front panel
Indicator Power ON/OFF, HDD
Speaker 8 Ohm, 0.4W, 1.5"
Power Supply Options PS/2 ATX power supply
Color Option  Black / Beige
Dimensions
( W x D x H )
483 (W) x 450 (D) x 177 (H) mm
Color Net Weight  13 kgs / 28.6 lbs
Operation Temperature -20~70 Celsius
Storage Temperature -30~80 Celsius
Relative Humidity 5% to 85%,non-condensing
Shock 10 G (with 11ms duration, half sine wave) (Operating), 30 G (Non-Operating)
    Download Drivers for Linux     Download Drivers for Windows

Product Sheet




Gallery





Part Number Description
 RM4018
4U Rackmount Chassis w/ 6.4" LCD touchscreen, case only
