                        2U Rackmount Chassis :  Model RM2035



19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard) or Custom
Motherboard Size: Support Size max to 9.6" x 9.6"
Drive Bays: 1x 5.25" Openbay & 2x 3.5" HDD(internal)
Drive Interface: SATA, U320 SCSI, or SAS
Power Supply: Single PS2 size or Mini-Redundant ATX PSU(Rear Installation) * Maximum Depth: 150mm
Cooling Units: 1 x 80mm(42.5CFM) Fan
Expansion Slot: 2x Front Side USB Port
4 vertical Low Profile Slots
Indicators: LEDs for Power ON/OFF and HDD, Activity, Fan
Buttons: Power ON/OFF Momentary (Rocker), System Reset
Dimensions:
(W x H x D)
19" x 3.5" x 13.9" / 483 x 88 x 650mm
Product Applications: 5% - 95% Non-condensing
Humidity: Web Server, Proxy Server, VPN Gateway, High-End Workstation, Print Server


Gallery




Ordering information
Part Number  Description
RM2035
 2U Rackmount Chassis,  Black, Case only.
RM2035-30
 2U Rackmount Chassis,  Black, w/ 300W P.S.
RM2035-40
 2U Rackmount Chassis,  Black, w/ 400W P.S.
