Short Depth 4K 18.4" 1U Rackmount Display Drawer
Model LCD1U19-023
SiriusView Short Depth 4K (UHD) 18.4 Inch 3840 x 2160 1U Rackmount Monitor Drawer
TAA Compliant
Short Depth 4K 18.4" 1U Rack Display Drawer
LCD1U19-023
|
Features & Benefits
- 1U Rackmout 18.4" 4K ( UHD ) Industrial Grade LCD Monitor Drawer
- 3840 x 2160 native resolution / 1.07B colors
- 1920 x 1080 & 1920 x 1200 resolution support
- Short Depth design of 18.1" (460 mm)
- DisplayPort 1.2 Video input
- Front panel and two point lock
- Built-in dual stereo speakers
- TAA compliant
Options
|
|
LCD Screen |
|
Display Size |
18.4.3" |
|
Panel Type |
4K Ultra High Defination ( UHD) |
|
Resolutions
|
Native Resolution up to 3840 x 2160
|
|
Viewing Angle
|
89/89/89/89 |
|
Contrast Ratio
|
1000
: 1 |
|
Brightness
|
300 cd/m2 |
|
MTBF (hrs)
|
30,000
|
|
Colors
|
1.07B
|
|
Response Time
|
15 ms
|
|
Dot Pitch
|
0.1065 mm
|
|
Surface Treatment
|
Anti-glare |
|
Surface hardness
|
3H |
|
Video |
|
Video Input |
DisplayPort 1.2 |
|
Video OPTION |
| |
HDMI 2.0 / HDCP 2.2
3G / HD / SD-SDI Broadcast-grade input |
|
Power Supply |
|
Input |
Auto-sensing 100 to 240VAC, 50 / 60Hz |
|
Environmental
|
|
Temperature
|
0 to 55
Degree Celsius (Operation)
-20 to 60 Degree Celsius (Storage) |
|
Relative Humidity
|
10~90%, non condensing (Operation)
5~90%, non condensing (Storage) |
|
Altitude
|
16,000 ft (Operating)
40,000 ft(Non-Operating) |
|
Shock
|
10G acceleration (11ms duration) |
|
Vibration |
10~300Hz 0.5G RMS random vibration |
|
Mechanical |
|
Product Dimension
|
17.4(W) x 18.1(D) x 1.73(H)inch /
442(W) x 460(D) x 44(H) mm
|
|
Product Weight
|
24.2lbs |
|
Mounting Range |
|
|
19.3" ~ 28.3"
490mm ~ 720mm
|
|
Compliance |
|
|
FCC & CE
REACH & RoHS3 /WEEE
CE/LVD & UKCA
TAA Compliant |
|
Free Ground Shipping. Learn More.
|
|
Ordering Information
| Part
Number |
Description |
LCD1U19-023
|
1U Rack mount 18.4" 4K Monitor Drawer with DP-1.2 + Speaker |
| Optional Video/Audio inputs |
-HDMI
|
HDMI-2.0 + DP-1.2 + Speaker |
|
-SDI
|
3G-SDI + DP-1.2 + Speaker |
|
| Optional
Touch screen |
| -TPC |
Projected Capacitive 10-Point Touch screen |
-TRB
|
Resistive 1-Point Touch screen |
| Optional
DC Input Power |
| -DC12 |
Change to 12V DC power supply |
| -DC24 |
Change to 24V DC power supply |
| -DC48 |
Change to 48V DC power supply |
-DC110
|
Change to 110V DC power supply |
-DC125
|
Change to 125V DC power supply |
-DC250
|
Change to 250V DC power supply |
| Optional
Lockable Jack |
| -MD |
MIL-type Lockable DC Power jack, Male |
|
| -MA |
MIL-type Lockable VGA jack, Male |
|
| -LD |
Lockable DC Power jack, Male |
|
| -LS |
Lockable USB jack for touch screen |
|
