1U 19" High Resolution Rack Mount LCD Drawer
Model LCD1U19-022
SiriusView 1U Rackmount 1920 x 1200 18" High Resolution Monitor Drawer
Short Depth Design
TAA Compliant
| 1U Rackmount Monitor
Drawer LCD1U19-022
|
Drawer Features & Display Benefits
- 1U 18" widescreen LCD drawer with HDMI & VGA input
- 1920 x 1200 native WUXGA Ultra high resolution
- Support Full HD with 1080p resolution
- PIP & Picture by Picture viewing efficiency
- Short depth design of 18.1" ( 460mm ) only
- TAA Compliant
Options
|
|
Panel: High Resolution 18" Widescreen LCD panel |
|
Backlight Type
|
LED
|
|
Resolutions
|
1920 x 1200 |
|
Response
time
|
9 ms
|
|
Contrast
ratio
|
1000 : 1 typical
|
|
Brightness ( typ. )
|
300 |
|
Dot pitch ( mm )
|
0.202
|
|
Panel
color
|
16.7 M, 8-bit
|
|
Viewing angle (H/V)
|
89/89/89/89 degree
|
|
Signal input |
VGA |
|
MTBF (hrs) |
50,000 |
Power |
Auto-sensing 100 to 240VAC, 50 / 60Hz
|
|
Product Dimension
|
17.4Wx 18.1D x 1.73H inch /
442W x 460D x 44H mm |
Storage
temp.
|
-20ºC to 60ºC
|
|
Operating
temp.
|
0ºC to 55ºC |
|
Relative Humidity
|
5 ~90%, non condensing (Storage)
10 ~90%, non condensing (Operation)
|
|
Shock
|
10G peak acceleration (11ms duration) |
|
Vibration
|
10~300Hz, 0.5G RMS random vibration |
|
Safety
Approval
|
FCC, CE
CE / LVD & UKCA
REACH & RoHS3 / WEEE
TAA Compliant |
|
|
|
|
Back to top
Ordering
Information
| Part
Number |
Description |
LCD1U19-022
|
1U 18" High Resolution Rackmount Monitor Drawer, with VGA + HDMI |
| Optional Video/Audio Inputs |
-HDMI
|
VGA + HDMI + Speakers for HDMI
|
|
-DVI
|
DVI-D + Audio + Speaker + VGA + HDMI |
|
-SDI
|
3G-SDI + Speaker + VGA + HDMI |
|
-DP
|
DP + HDMI-2.0 + HDMI-1.4 + Audio + Speaker + VGA |
|
-BNC
|
BNC + Audio IN + Speaker + VGA + HDMI |
|
Optional DC power |
-DC12
|
Change to 12V DC power supply |
-DC24
|
Change to 24V DC power supply |
-DC48
|
Change to 48V DC power supply |
-DC110
|
Change to 110V DC power supply |
-DC125
|
Change to 125V DC power supply |
-DC250
|
Change to 250V DC power supply |
