1U Rackmount 19" FULL HD LCD Monitor Drawer
Model LCD1U19-021
SiriusView 1U Rack Mount 18.5"
Outdoor High Brightness Sunlight Readable FHD LCD Drawer
TAA Compliant
| LCD1U19-021
|
Drawer Features & Display Benefits
- 1U 19" High Brightness FHD 1080p LED-backlit Monitor Drawer
- 1920 x 1080 native resolution / 16.7M colors ( 8-bit ) / 1000 cd/m² brightness
- Short depth design of 18.9" (480mm ) only
- TAA Compliant
Options
- 3G / HD / SD-SDI Broadcast-grade input + Speakers
- DisplayPort (DP) + Speakers
- DVI-D + Audio input & output + Speakers
- Composite Video + Audio input + Speakers
- Dual stereo speakers for HDMI
- 250V , 125V , 110V , 48V, 24V or 12V DC power
|
|
|
General
Information |
|
Form Factor |
1U Rack mounting on slide-out rails |
| LCD Screen |
|
LCD Type
|
High Brightness Active Matrix TFT
|
|
Display Size
|
18.5 inch diagonal
|
|
Backlight
|
LED
|
|
Display Area |
408.98 x 230.04 mm (HxV) |
|
Resolutions
|
1920 x 1080 |
|
Contrast
ratio
|
1,000
: 1
|
|
Brightness
|
1000
cd/ m2
|
|
Dot pitch
|
0.213 mm
|
|
Response time
|
20 ms |
|
Panel
color
|
16.7 M |
|
Viewing
angle
|
89/89/89/89 ( L/R/U/D) |
|
Signal Input
|
VGA / HDMI
|
|
Surface treatment |
Anti-glare, Hard-coating |
|
Surface hardness |
3H |
|
LCD MTBF |
50,000 hrs |
|
Power Supply |
|
Input |
Auto-sensing 100 to 240VAC, 50 / 60Hz |
|
Consumption |
Screen on : Max. 40 Watt
Power saving mode : Max 2 Watt
Power button on : Max 1 Watt |
|
Environmental
|
|
Storage
temp.
|
-20ºC to 70ºC
|
|
Operating
temp.
|
-20ºC to 70ºC |
|
Relative Humidity
|
5 ~90%, non condensing (Storage)
10 ~90%, non condensing (Operating) |
|
Shock
|
10G peak acceleration (11ms duration) |
|
Altitude
|
16,000 ft (Operating)
40,000 ftn(Non-Operating) |
|
Vibration
|
10~300Hz 0.5G RMS random vibration |
|
Mechanical |
|
Dimension: |
442 x 440 x 44 mm / 17.4 x 17.3 x 1.73 inch (WxDxH) |
|
Product Weight
|
11 kgs / 24.2 lbs |
|
Regulatory Approval |
|
|
FCC & CE
REACH & RoHS3 /WEEE
CE/LVD & UKCA
TAA Compliant |
|
Free Ground Shipping. Learn More.
|
Ordering Information
| Part
Number |
Description |
LCD1U19-021
|
1U
Rackmount 19" High Brightness FHD Monitor Drawer, VGA + HDMI |
| Optional Video/Audio Inputs |
-HDMI
|
VGA + HDMI + Speakers for HDMI
* Chassis depth extended to 20.87"/530mm |
|
-DVI
|
DVI-D + Audio + Speaker + VGA + HDMI
* Chassis depth extended to 20.87"/530mm |
|
-DP
|
DisplayPort + VGA + HDMI + Speaker
* Chassis depth extended to 20.87"/530mm |
|
-BNC
|
BNC + Audio IN + Speaker + VGA + HDMI
* Chassis depth extended to 20.87"/530mm |
|
-AV
|
BNC with RCA adapter + Audio IN + Speaker + VGA + HDMI
* Chassis depth extended to 20.87"/530mm |
|
-SDI
|
3G-SDI + VGA + HDMI + Speaker
* Chassis depth extended to 20.87"/530mm |
|
Optional DC power |
| -DC12 |
Change to 12V DC power supply
* Chassis depth extended to 20.87"/530mm |
|
| -DC24 |
Change to 24V DC power supply
* Chassis depth extended to 20.87"/530mm |
|
| -DC48 |
Change to 48V DC power supply
* Chassis depth extended to 20.87"/530mm |
|
-DC110
|
Change to 110V DC power supply
* Chassis depth extended to 20.87"/530mm |
|
-DC125
|
Change to 125V DC power supply
* Chassis depth extended to 20.87"/530mm |
|
-DC250
|
Change to 250V DC power supply
* Chassis depth extended to 20.87"/530mm |
|
