1U Single console 8 Port DVI KVM switch
Part # LCDK3001
1U Rackmount Single user 8-port DVI-USB KVM Switch with 8 x DVI-D + 8 x USB cables
TAA Compliant
-Firmware Up-gradable
-AUDIO&MIC + 2-PORT USB 2.0 HUB & USB HOTKEYS
-TMDS SPECIFICATION COMPLIANT
-DIGITAL & ANALOG VIDEO SUPPORT
The LCDK3001 is a TMDS-compliant 8-port DVI USB KVM Switch with Audio and Microphone switching function. It allows you to control 8
USB-enabled multimedia computers with DVI video interfaces, using only one USB keyboard, mouse, monitor and a set of speakers and microphone. This DVI USB KVM Switch supports both digital video (1920 x 1200) and analog video (2048 x 1536) for your maximum
convenience in adapting to your display requirements
You can select the computers, USB device hub port control and audio/mic channels either simultaneously or independently, using either frontpanel
buttons or keyboard hotkeys. This DVI USB KVM Switch adopts the DVI interface technology that implements genuinely digital signal
transmission over the cable to reduce undesired distortion from conventional analog/digital conversion. It isTMDS compliant to support DDC2B
emulation and HDCP compliant for digital contents protection.
|
|
|
| |
|
 |
|
Features:
▪ 8-port DVI USB KVM switch with audio and microphone switching and 2 x USB 2.0 hub ports
▪ TMDS specifications compliant
▪ VESA DDC2B emulation
▪ TMDS signal pass through
▪ HDCP specifications compliant
▪ USB Keyboard and mouse support
▪ USB 2.0 Specification compliant
▪ DVI Single Link technology supports digital video signal transmission
▪ Independent/simultaneous USB hub port, audio & mic channels and PC port selection
▪ Support for Windows 98/SE/ME/2000/XP/Vista and Linux and Mac OS
▪ Built-in 2-port USB 2.0 device hub for sharing high-speed USB devices
▪ Multi-platform support for PCs and Macintosh G3/G4 MACs, iMACs
▪ Channel selection/Hub port control by front-panel push buttons and keyboard hotkeys
▪ Resolution support up to 2048 x 1536 (analog) / 1920 x 1200 (digital)
▪ Firmware up-gradable via USB port
More photos (click to enlarge )
|
|
Technical Specification |
|
PC Connections |
8 |
| Console Connections |
1 |
| PC Port Connectors |
8 x USB Type B
8 x DVI-D Single Link [digital only[
8 x 3.5mm audio in/out jack
8 x 3.5mm mic in/out jack |
| Console Port Connectors |
2 x USB 1.1 Type A for Keyboard/Mouse
1 x DVI-D Single Link [digital only[
1 x 3.5mm audio in/out jack
1 x 3.5mm mic in/out jack |
| USB hub ports |
2 x USB 2.0 Type A device hub port |
| PC selection |
USB Hotkey / Push buttons |
| PC port LED |
8 |
| Hub port LED |
8 |
| Scan delay time |
5 ~ 100 sec programmable |
|
Digital Display Resolution |
2048 x 1536 [analog] / 1920 x 1200 [digital] |
|
Firmware Upgrade |
Yes / via USB port |
|
Power Adapter |
DC 9V 1A (required) |
|
Housing |
Metal case + plastic front |
|
Safety / Emission |
FCC, CE , TAA Compliant |
Ordering
information
| Part
Number |
Description |
|
LCDK3001
Price : $665 |
1U Rackmount Single user 8-port DVI-USB KVM Switch with 8 x DVI-D cables + 8 x USB cables |
|
|
