Key Specifications/Special Features:
Input:
AC input: universal input 100 to 132 or 198 to 264VAC, auto selectable 50 to 60Hz
Maximum inrush current: 40A for 110VAC cold start; 20A for 220VAC cold start

Output: Output 1 / Output 2 / Output 3 / Output 4 / Output 5
Voltage: +5 / +12 / -5 / -12 / 3.3VDC
Maximum load: 30 / 12 / 0.5 / 0.8 / 14A
Minimum load: 3 / 2 / 0.1 / 0.1 / 0.3A
(output 1 + output: 150W)
Ripple: 50 / 120 / 50 / 120 / 40mV
Ripple / noise: 100 / 150 / 100 / 240 / 40mV
Line regulation: +/-1% / +/-1% / +/-1% / +/-1% / +/-1%
Output regulation: +/-5% / +/-5% / +/-10% / +/-10% / +/-5%
Cross regulation: +/-5% / +/-5% / +/-10% / +/-10% / +/-5%
Remote on / off control: +5V SB DC output 750mA (peak 1.2A)
When PS-on is pulled to TTL Low, the DC output is to be enabled
When PS-off is pulled to TTL high, the DC output is to be disabled
Total output power: 300W continuous maximum
Efficiency: minimum 65% at full load
Hold-up time: 16ms at maximum load and normal input voltage
Power good: TTL compatible signal out with 100ms to 500ms
Short circuit protection: all output equipped with short circuit protection
Overpower protection: peak power is protected between 130% and 160% of continuous rated power
Hot swappable and power sharing
Dimensions: 119 x 260 x 86.00mm (W x L x H)
Environment conditions:
Operating temperature: 0 to 50 degrees Celsius
Cooling: by forced air
Storage temperature: -20 to 70 degrees Celsius
Humidity: 5 to 90%, non-condensing.

Safety/Quality Approval Details:
UL CUL TUV CB CE NEMKO
